Features
SPEEDPERFECT®
Provides up to 40% faster washing time. (*As compared to Perm Press Heavy Soil cycle without SpeedPerfect™).
Additional Features
ECOSILENCE™
Delivers quiet, efficient and long lasting performance.
Specifications
General
Series
300 Series
Color
White
Manufacturer Color
White
Tub Material
Stainless Steel
Maximum Speed
1400 rpm
Capacity
Total Capacity IEC
2.2 cu. ft.
IEC (By Class)
3 cu.ft. and below
Cycle Information
Number of Cycles
15
Wash Cycles
Special Cycles: Allergen, Jeans, Heavy Duty
Options
• Number of options: 6
• Special Cycles: SpeedPerfect®, PreWash
• Special Cycles: SpeedPerfect®, PreWash
Features
Stackable
Yes
Reversible Door
No
Additional Information
• Leak protection systems: Reinforced Hose
• Internal water heater
• Silence level – washing: 52 dBA
• Silence level – spinning: 72 dBA
• Water consumption: 2,288 gal/yr
• Door hinge: Left Side
• Internal water heater
• Silence level – washing: 52 dBA
• Silence level – spinning: 72 dBA
• Water consumption: 2,288 gal/yr
• Door hinge: Left Side
Electrical Information
Information
• Energy consumption: 84 kWh/yr
• Watts: 2,520 W
• Circuit breaker: 15 A**
• Volts 208/220-240 V
• Current 10.5 A
• Frequency 60 Hz
• Power Cord (included): 240V; NEMA 6-15, 3-prong
**Stated circuit breaker size is if the appliance is plugged into an individual 240/208V, 15A minimum branch circuit
• Watts: 2,520 W
• Circuit breaker: 15 A**
• Volts 208/220-240 V
• Current 10.5 A
• Frequency 60 Hz
• Power Cord (included): 240V; NEMA 6-15, 3-prong
**Stated circuit breaker size is if the appliance is plugged into an individual 240/208V, 15A minimum branch circuit
Certifications and Approvals
Energy Star Certified
Yes
Information
• UL listed
• ADA compliant:
Meets ADA height and access requirements when installed on a pedestal
Meets ADA operable parts requirements for controls and detergent dispenser
• ADA compliant:
Meets ADA height and access requirements when installed on a pedestal
Meets ADA operable parts requirements for controls and detergent dispenser
Accessories
Optional
Power Adapters:
• WTZPA20UC: 4-Prong
• WTZPA30US: 3-Prong
Matching Bosch Dryers are supplied with WTZPA20UC adapter to fit a standard 4-Prong, 30A, Dryer receptacle (NEMA 14-30R) to power both Bosch Washers and Dryers.
• 3-Prong Adapter may be ordered directly from Bosch (not supplied with Washer or Dryer)
• Use of two individual NEMA 6-15R or 6-20R receptacles/circuits may be used as alternative means to power the Washer and Dryer
Dryer Stacking Kits:
• WTZ11400UC: Kit w/Shelf
• WTZ20410UC: Kit w/out Shelf
• WTZSB30UC: Kit w/Brackets
Necessary only when stacking a matching Bosch dryer on top of the washer.
• WMZPW20W: Washer Pedestal
• WTZPA20UC: 4-Prong
• WTZPA30US: 3-Prong
Matching Bosch Dryers are supplied with WTZPA20UC adapter to fit a standard 4-Prong, 30A, Dryer receptacle (NEMA 14-30R) to power both Bosch Washers and Dryers.
• 3-Prong Adapter may be ordered directly from Bosch (not supplied with Washer or Dryer)
• Use of two individual NEMA 6-15R or 6-20R receptacles/circuits may be used as alternative means to power the Washer and Dryer
Dryer Stacking Kits:
• WTZ11400UC: Kit w/Shelf
• WTZ20410UC: Kit w/out Shelf
• WTZSB30UC: Kit w/Brackets
Necessary only when stacking a matching Bosch dryer on top of the washer.
• WMZPW20W: Washer Pedestal
Dimensions
Class Width
25" And Under
Width
23.5 inch(es) / 59.69 cm
Height
33.25 inch(es) / 84.46 cm
Depth
24.25 inch(es) / 61.6 cm
Weight
163.01 lb(s) / 73.94 kg
Additional Dimensions
• Power cord length 63" (Full Length)
• Drain hose length 57" (Full Length)
• Inlet hose length 48" (Full Length)
• Drain hose length 57" (Full Length)
• Inlet hose length 48" (Full Length)
