Features
CAPTUR™ SYSTEM
The Broan Captur™ exhaust ventilation system provides the fastest air flow management and filtration in its class for better performance quieter operation and less energy use.
Additional Features
LIGHTING BUILT-IN LED MODULES
Lighting built-in LED modules that provide an even lighting over the cooktop.
Specifications
General
Series Name
Sahale Series
Blower Included
Yes
Airflow
400 CFM
Style
Standard
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Under-Cabinet
Features
Technologies
CapturTM
Ducting Information
• Ducting Size 3-1/4 in X 10 in (H-V) or 7 in Round
• Non-Ducted Re-circulation Capable
• Non-Ducted Re-circulation Capable
Speeds
3
Additional Information
• 3-level lighting built-in LED modules (2) that provide an even lighting over the cooktop
• Two deluxe high efficiency micro filters, easy to clean
• Filter clean reminder
• 10 minute delay off setting
• Automatic heat sensor function
• Performant dual blower
• Quietest range hood offering a sound level of 0.3 sone at low speed
• Use charcoal filter HPF30 for a non-ducted installation
• EZ 1 brackets make it easy for single-person installation in less than half the time of traditional methods
• ADA compliant, remote operation is possible using a standard UL approved momentary wall switch. Requires ADA Wiring Kit
• Two deluxe high efficiency micro filters, easy to clean
• Filter clean reminder
• 10 minute delay off setting
• Automatic heat sensor function
• Performant dual blower
• Quietest range hood offering a sound level of 0.3 sone at low speed
• Use charcoal filter HPF30 for a non-ducted installation
• EZ 1 brackets make it easy for single-person installation in less than half the time of traditional methods
• ADA compliant, remote operation is possible using a standard UL approved momentary wall switch. Requires ADA Wiring Kit
Electrical Information
Information
• 120 Volts
• 1.4 Amps
• 1.4 Amps
Certifications and Approvals
Hvi Certified
Yes
Energy Star Certified
No
Accessories
Optional
• HPFA3A30 replacement filters
• HPF30 charcoal replacement filters
• HAWRK3 ADA wiring kit
• HPF30 charcoal replacement filters
• HAWRK3 ADA wiring kit
Dimensions
Class Width
30"
Shipping Dimensions
Width
29.88 inch(es) / 75.9 cm
Height
5 inch(es) / 12.7 cm
Depth
19.88 inch(es) / 50.5 cm
Warranty
Warranty
1 Year. 3 Years on LED modules
UPC
UPC#
26715244027
