Features
CUSTOM-SET™ TOUCH CONTROLS
Integrated within the cooking surface for a clean look, electronic touch-controls give you accurate control over cooking temperatures.
Additional Features
EXPANDABLE ELEMENTS
Flexible elements with up to 4,400 watts of power expand to fit virtually any pan size so you have the utmost versatility.
COOKING TIMER
A cooking timer is conveniently located on the cooktop.
WAVE TOUCH CONTROLS
Sleek control panel illuminates with a touch providing you with multiple cooking options and fades away to an uncluttered display after an option is selected.
KEEP WARM SETTING
Maintains your ideal serving temperature for all your
favorite foods.
Specifications
General
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Fuel Type
Electric
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• 1 x 1,000/1,800/2,700W
• 2 x 1,200W
• 1 X 1,700/2,700W
• 2 x 1,200W
• 1 X 1,700/2,700W
Burner/Element Size
• 5/7/9 inches
• 9/12 inches
• 2 x 6 inches
• 9/12 inches
• 2 x 6 inches
Elements
Smoothtop
Features
Technologies
• Wave-Touch® Controls
• Custom-SetTM Touch-Controls
• Custom-SetTM Touch-Controls
Clock
No
Control Lock
Yes
Digital Display
Yes
Downdraft Ventilation
No
Additional Information
• Ceramic Smoothtop Glass: Glass cooktop is flat, smooth and easy to clean and maintain.
• Electronic Touch-Controls: The smooth cooktop surface is undisturbed with knobs for a look that is sleek and flush with your countertop.
• Hot Surface Indicator: For added safety, when an element is still hot, a blue LED indicator will stay on until surface cools.
• Electronic Touch-Controls: The smooth cooktop surface is undisturbed with knobs for a look that is sleek and flush with your countertop.
• Hot Surface Indicator: For added safety, when an element is still hot, a blue LED indicator will stay on until surface cools.
Electrical Information
Information
• 240/208 V
• 40 A
• 60 Hz
• 40 A
• 60 Hz
Certifications and Approvals
Sabbath Mode
No
Dimensions
Class Width
30"
Width
30.75 inch(es) / 78.11 cm
Height
3 inch(es) / 7.62 cm
Depth
21.5 inch(es) / 54.61 cm
Weight
42.09 lb(s) / 19.09 kg
Additional Dimensions
Cut-out dimensions: Depth 20-1/8"- 20-1/4" Height 6-1/4" Width 29-7/8"- 30"
Shipping Dimensions
Weight
48.1 lb(s) / 21.82 kg
Warranty
Warranty
1 Year
UPC
UPC#
057112094854
