Features
HUEBSCH PERFECT WASH™
Versatile, gentle and delivering a great clean, Huebsch’s Perfect Wash enables you to tailor wash cycles for the ultimate fabric care. Truly innovation that gets clean results.

ULTRA QUIET (43DB)
Sleeping babies, nervous dogs, team calls from the home office – there are plenty of reasons we like a quiet atmosphere in the house. We get it…and make sure our machines oblige measuring in at only 43dB during agitation.

LEGENDARY RELIABILITY
Our legend status may have been born more than 110 years ago, but we earn it every day. Built for 25 years of life in the average home.

OUT-OF-BALANCE MANAGEMENT
Commercial quality means running all cycles to completion even the most out-of-balance ones. We do this with a combination of commercial components and technology others can’t match.

Specifications
General
Series
TR5
Wash Action System
Agitator
Color
White
Manufacturer Color
White
Tub Material
Stainless Steel
Maximum Speed
820 rpm
Temperature Settings
4
Capacity
Total Capacity IEC
3.2 cu. ft.
IEC (By Class)
3.1 cu.ft. - 3.5 cu.ft.
Cycle Information
Number of Cycles
6
Wash Cycles
• Heavy Duty
• Normal Eco
• Delicate
• Perm Press
• Handwash
• Spin
• Normal Eco
• Delicate
• Perm Press
• Handwash
• Spin
Options
Heavy Soil
Features
Technologies
Speed Queen Perfect Wash™
Dispensers
• Bleach
• Fabric Softener
• Fabric Softener
Additional Information
• Load Size Selections: Small, Large, Auto Fill, Auto Fill Extra Rinse
• Variable Speed 1 H.P. Motor
• Automatic Balancing System
• Quiet Agitation (43dB)
• Porcelain Outer Tub
• Durable 3 - Coat Finish
• End-of-Cycle Signal
Extra Rinse • 2 Soil Level Selections
• 4 Temperature Selections
• Variable Speed 1 H.P. Motor
• Automatic Balancing System
• Quiet Agitation (43dB)
• Porcelain Outer Tub
• Durable 3 - Coat Finish
• End-of-Cycle Signal
Extra Rinse • 2 Soil Level Selections
• 4 Temperature Selections
Certifications and Approvals
Information
cULus
Accessories
Optional
Fill Hose
Dimensions
Class Width
26" - 27"
Width
25.63 inch(es) / 65.1 cm
Height
42.76 inch(es) / 108.6 cm
Depth
27.99 inch(es) / 71.1 cm
Additional Dimensions
Height with Lid Open: 1346 mm (53 in.)
Shipping Dimensions
Weight
195.99 lb(s) / 88.9 kg
Warranty
Warranty
Limited 5 Years Parts and Labor
