Victory 36-inch Star Hood Insert STAR-36

VictorySKU: STAR36
The Victory Star comes with mechanical rotary switches, making this range one of our most reliable models. Designed, assembled, and... The Victory Star comes with mechanical rotary switches, making this range one of our most reliable models. Designed, assembled, and certified in Canada for long-lasting, problem-free service a 5-year parts warranty on this model.This model comes with a powerful 900 CFM all-metal double blower, making it ideal for anyone who cooks a lot. An 8" duct is required for this range hood to reach 900 CFM and keep the noise levels low.Most insert range hoods on the market are shallow and don't cover your cooktop effectively, but we designed the Victory Star 21" deep for efficiency and effective coverage over your burners. View more
Features Specifications Documents
Features
DISHWASHER SAFE STAINLESS STEEL FILTERS
Discover the Advantages of our Easy-to-Clean, Dishwasher Safe Stainless Steel Filters. Never replace a filter again.
DISHWASHER SAFE STAINLESS STEEL FILTERS
FULLY MECHANICAL
Enjoy Unbeatable Reliability with our Mechanical Rotary Knob Controls. A simpler, less complicated experience.
FULLY MECHANICAL
BRIGHT LED LIGHTING
Discover the long-lasting Brilliance of GU10 Bulbs, Easily Available at any Hardware Store. Illuminate Your World for those Special Moments.
BRIGHT LED LIGHTING
ALL-METAL IMPELLER with LIFETIME Warranty
Reliable Blower with a LIFETIME* Warranty: The Ultimate Choice for Long-lasting Performance. It's true that what's inside matters most.
ALL-METAL IMPELLER with LIFETIME Warranty
Specifications
General
Series Name
Star
Blower Included
Yes
Airflow
900 CFM
Style
Custom Insert
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Built-In
Features
Dishwasher-Proof Filters
Yes
Ducting Information
8" Round Exhaust
Speeds
4-Speed Mechanical Rotary Switch
Additional Information
• Dimmable LED Lights
• Dishwasher Safe Stainless Steel Baffle Filters
• Motor Revolution: 800 RPM (±10%) to 1300 RPM (±10%)
• Noise Level: 1.5 Sone(46dB) / 3.5 Sone(58dB) / 5.3 Sone(64dB) / 7.5 Sone (69dB)
• Motor Type: Single Chamber Ultra Quiet
• Fan Type: Centrifugal
• Control Type: Mechanical, Rotary Switches
Electrical Information
Information
• Power Rating: 120V/60Hz (USA & Canada standard)
• General Input Power: 345W (240W + 3x35W), 380W (240W + 4x35W)
• Motor Input Power: 240 W (120W + 120W)
Dimensions
Class Width
36"
Width
33 inch(es) / 83.82 cm
Height
10 inch(es) / 25.4 cm
Depth
19.62 inch(es) / 49.84 cm
Warranty
Warranty
5 Year Parts
